Description
Flat rate shipping click HERE
An ideal choice for cooling beer, wine, or other beverages in settings with low capacity for conventional refrigeration. Similar in concept to a jockey box, this unit will cool up to 4 different beverages at once.
DESCRIPTION
Flash chiller is an ideal choice for cooling draft beer, wine on tap, and other carbonated or non-carbonated beverages in places with limited possibilities for other types of refrigeration.
This particular model T120F-1/3T4 has 4 product lines, which means you can cool up to 4 different beverages at once, which is quite handy for small bars and restaurants. Quick cooling is achieved thanks to the 4 x 50' stainless steel coils covered with ice-cold water.
Construction-wise, draft beer & wine keg cooling stations share some similarities with jockey boxes since they have an icebank with a stainless steel coil, which has to be covered with ice-cold water. The submerged agitator pump ensures quick and efficient cooling in any circumstances.
FEATURES
Capacity: from 1 to 4 product lines
Works with most beverages - alcoholic (beer or wine) and soft drinks (juice, seltzer, or water)
Cooling is achieved via running the product lines through 50’ stainless steel coils covered with ice-cold water
Icebank capacity: 44 lbs
Great for commercial use at bars, restaurants, and sports venues
SPECIFICATIONS
Part Number
T120F-1/3T4
Maximum Distance, Ft
25'
Capacity-Compressor (evap 20F), BTU/hr
2600
Capacity-Ice Bank, BTU/hr
5500
Ice Bank, Lbs
44
Dedicated Circuit, Amp
15
Voltage, Volt/Hz
115/60
Power Consumption, Watt
750
Compressor Power, HP
1/3hp
Thermostat, Type
Manual
Number of Product Lines, Coils
4
Coil Diameter, ID-OD, In
1/4" - 5/16"
Coil Length (total), Ft
200
Pump Type, Part Number
FloJet SPC42
Pump Flow Rate, Gal/Hr (water)
240
Refrigerant, Type
R134a
Dimensions - WxDxH, In
17x19x30
Weight Net/Gross lbs
97/106
DOWNLOADS
SPECIFICATIONS
An ideal choice for cooling beer, wine, or other beverages in settings with low capacity for conventional refrigeration. Similar in concept to a jockey box, this unit will cool up to 4 different beverages at once.
DESCRIPTION
Flash chiller is an ideal choice for cooling draft beer, wine on tap, and other carbonated or non-carbonated beverages in places with limited possibilities for other types of refrigeration.
This particular model T120F-1/3T4 has 4 product lines, which means you can cool up to 4 different beverages at once, which is quite handy for small bars and restaurants. Quick cooling is achieved thanks to the 4 x 50' stainless steel coils covered with ice-cold water.
Construction-wise, draft beer & wine keg cooling stations share some similarities with jockey boxes since they have an icebank with a stainless steel coil, which has to be covered with ice-cold water. The submerged agitator pump ensures quick and efficient cooling in any circumstances.
FEATURES
Capacity: from 1 to 4 product lines
Works with most beverages - alcoholic (beer or wine) and soft drinks (juice, seltzer, or water)
Cooling is achieved via running the product lines through 50’ stainless steel coils covered with ice-cold water
Icebank capacity: 44 lbs
Great for commercial use at bars, restaurants, and sports venues
SPECIFICATIONS
Part Number
T120F-1/3T4
Maximum Distance, Ft
25'
Capacity-Compressor (evap 20F), BTU/hr
2600
Capacity-Ice Bank, BTU/hr
5500
Ice Bank, Lbs
44
Dedicated Circuit, Amp
15
Voltage, Volt/Hz
115/60
Power Consumption, Watt
750
Compressor Power, HP
1/3hp
Thermostat, Type
Manual
Number of Product Lines, Coils
4
Coil Diameter, ID-OD, In
1/4" - 5/16"
Coil Length (total), Ft
200
Pump Type, Part Number
FloJet SPC42
Pump Flow Rate, Gal/Hr (water)
240
Refrigerant, Type
R134a
Dimensions - WxDxH, In
17x19x30
Weight Net/Gross lbs
97/106
DOWNLOADS
SPECIFICATIONS
SKU: 410347
