UBC Tayfun | Flash Beer Chiller, 2 Lines with Digital Thermostat (V30)

Flat rate shipping click HERE (?)
An ideal choice for cooling beer, wine, or other beverages in settings with low capacity for conventional refrigeration. Similar in concept to a jockey box, this unit will cool up to 2 different beverages at once.
DESCRIPTION

Flash chiller is an ideal choice for cooling draft beer, wine on tap, and other carbonated or non-carbonated beverages in places with limited possibilities for other types of refrigeration.
This particular model V-30 has 2 product lines, which means you can cool up to 2 different beverages at once, which is quite handy for small bars and restaurants. Quick cooling is achieved thanks to the 2x71' stainless steel coils covered with ice-cold water.
Construction-wise, draft beer & wine keg cooling stations share some similarities with jockey boxes since they have an icebank with a stainless steel coil, which has to be covered with ice-cold water. The submerged agitator pump ensures quick and efficient cooling in any circumstances.
FEATURES














Capacity: from 1 to 2 product lines
Works with most beverages - alcoholic (beer or wine) and soft drinks (juice, seltzer, or water)
Cooling is achieved via running the product lines through 71’ stainless steel coils covered with ice-cold water
Icebank capacity: 19 lbs

Great for commercial use at bars, restaurants, and sports venues




SPECIFICATIONS










Part Number
V30F-1/4T2


Maximum Distance, ft
n/a


Capacity (evap 20F), BTU/hr
1900


Ice Bank, lbs
19


Dedicated Circuit, amp
15


Voltage/Hz
115/60


Compressor Power, hp
3/8hp


Thermostat Type
Manual


Number of Product Lines, Coils
2


Coil Diameter, ID-OD
5/16"-3/8"


Coil Length (total), ft.
71


Pump Type
Saber agita-tor


Refrigerant Type
R134a


Dimensions WxDxH, in
28x19x13


Weight Net/Gross Lbs.
101/115
