Description
Flat rate shipping click HERE
24" wide shallow depth built-in under-counter ADA compliant beverage centre with glass door, stainless steel interior, black cabinet, lock, and digital controls.
KEY FEATURES
Frost Free
Built-in Capable
Digital Thermostat
Dimmable LED Lighting
CARB Compliant
Keyed Lock
32.0"H x 23.38"W x 17.75"D
DESCRIPTION
Summit's shallow depth series of built-in undercounter refrigeration brings full functionality to kitchen islands, wet bars, and other settings with space limitations.
Model ASDG2411 is a 24" wide beverage refrigerator sized under 18" deep. It comes in a 32" height to fit under lower ADA compliant counters, with adjustable legs and a sliding kickplate cover that also allows you to raise the overall height up to 34" to fit standard counter spaces. The front-breathing system allows built-in installation, while the fully finished black cabinet also allows freestanding use. Seamless stainless steel trim blends smoothly into the double pane tempered glass door for an elevated look, with a professional stainless steel handle included. This unit has a sealed rear and right angle cord for a better fit. The door is user-reversible and includes a front lock.
Inside, the ASDG2411 features stainless steel construction for improved durability and sanitation. Fan-forced cooling ensures even temperature distribution and fast temperature recovery. This unit includes an LED strip on each side of the interior cabinet, with dimmable settings in a gentle white hue that lets you create the perfect display conditions. Commercial grade cantilevered shelving in chrome offers flexible storage to accommodate any size. Additional features include an open door alarm, high temperature alarm, and Sabbath mode setting that lets you disable some of the electrical elements during periods of observance.
The ASDG2411 is ETL-S listed to NSF-7 commercial standards but can also be used in the home. With its deluxe style, user-friendly features, and uniquely shallow depth, this unit offers premium value for a variety of settings. Create a matching set by pairing this with our ASDW2412 wine cellar. Additional 18" deep choices are available in 15", 19", and 24" widths, including outdoor refrigerators, refrigerator drawers, wine cellars, and more.
FEATURES
24" wide beverage center
3.25 cu.ft. interior for residential or commercial cold storage
Less than 18" deep
Unique 17.75" shallow depth is ideal for wet bars, island kitchens, and other undercounter areas with limited footprint space
ADA compliant design
32" height allows easy installation under lower ADA compliant counters
Adjustable height
Leveling legs can be extended up to 2", with a slide-out kickplate that allows you to raise the overall height from 32" up to 34" if used under more standard sized cabinets
Built-in capable
Front-breathing design lets you make the best use of space by installing your appliance under the counter
Stainless steel interior
Walls and floor are constructed from stainless steel for added strength and easy cleanup
Double pane tempered glass door
Elegant design offers a clear but protected view of your interior
Seamless stainless steel door trim
Glass is framed by with a flush one-piece stainless steel trim for an elevated look
Factory installed lock
Keyed lock for a secure interior (2 keys included)
Professional handle
Stainless steel handle completes the look
Digital thermostat
Electronic controls located inside the unit for precise temperature management, with a readout viewable in Celsius or Fahrenheit at the touch of a button
Dimmable LED lighting
Efficient and attractive presentation with white LED lighting strips located on each side of the cabinet that can be adjusted between three levels of brightness
Frost-free operation
No-frost operation for minimum user maintenance
Internal fan
Fan-forced cooling ensures fast temperature recovery and that the unit is evenly cooled from top to bottom
Cantilevered shelving
Adjustable chrome shelves with stainless steel clips allow you to adjust the shelf height for the best fit
Open door alarm
Audible alarm will sound if the door is left open longer than one minute
High temperature alarm
High temperature alarm sounds if the unit's interior goes out of the recommended range
Sabbath mode setting
Optional setting lets you disable the lighting and alarm for up to 48 hours
Temperature Memory Function
Unit will retain its last settings when power is restored in the event of power loss
Right angle plug
Design allows you to plug the unit in flush against the wall socket with no need to add extra depth
Sealed back
Space-saving design with no exposed coils that offers easier cleanability
Integrated hinge
Flat hinge ensures no added height is needed when installing under a counter
Reversible door
User-reversible door swing for added flexibility
Fully finished black cabinet
Allows the unit to be used freestanding
Commercially approved
ETL-S listed to NSF-7 Standards and meets UL-471 for use in commercial establishments
100% CFC Free
Environmentally friendly design with no ozone-damaging chemicals
CARB Compliant
Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
SPECIFICATIONS
Overview
Height of Cabinet
32.0" (81 cm)
Width
23.38" (59 cm)
Depth
17.75" (45 cm)
Depth with Handle
19.63" (50 cm)
Depth with door at 90°
39.88" (101 cm)
Capacity
3.25 cu.ft. (92 L)
Defrost Type
Frost-Free
Door
Glass
Cabinet
Black
US Electrical Safety
ETL
Canadian Electrical Safety
ETL-C
Sanitation
ETL-S
Energy Usage/Year
285.0kWh/year
Amps
1.0
Voltage/Frequency
115 V AC/60 Hz
Weight
120.0 lbs. (54 kg)
Shipping Weight
140.0 lbs. (64 kg)
Parts & Labor Warranty
1 Year
Compressor Warranty
5 Years
UPC
761101079455
Refrigerator Features
Sabbath Mode
Yes
Door Swing
RHD
Reversible
Yes
Height Adjustable
Yes
Shelf Type
Chrome
Shelf Qty
3
Adjustable Shelves
Yes
Thermostat Type
Digital
Fan Type
Interior and Exterior
Refrigerant Type
R600a
Refrigerant Amount
1.38oz.
High Side PSI
270.0
Low Side PSI
105.0
Level Legs Qty
4
Interior Light
Yes
Temperature Range
36 to 43ºF
Sound Level
33.1 dB
Dimensions
Interior Height
24.5" (62 cm)
Interior Width
19.5" (50 cm)
Interior Depth
12.25" (31 cm)
Compressor Step Height
3.75" (10 cm)
Compressor Step Width
19.5" (50 cm)
Compressor Step Depth
4.5" (11 cm)
DOWNLOADS
BROCHURE w/ DRAWINGS ASDG2411.pdf
TECHNICAL DRAWING (.dwg) ASDG2411.dwg
ASSEMBLY DRAWINGASDG2411-Assembly.pdf
USE & CARE
SCR610BLSD_ALBV15_SCR1400W_ASDG1521_Use_and_Care_04-26-2022.pdf.pdf
MSDS INFORMATIONR600a_K.pdf
